Watlow EZ-ZONE ® RUI/Gateway • 21 • Chapter 4 RUI Page
Chapter 4: RUI Page
4
The RUI Page
To go to the RUI Page from the Home Page, press both
the Down ¯ and Advance ‰
keys for three seconds.
[L] (local) will appear in the Zone Display, [CoM] will
appear in the upper display and [`rUi] will appear in
the lower display.
• Press the Up ¿ or Down ¯ key to move through
the menus.
• Press the Advance Key ‰ to select a menu.
• Press the Advance Key ‰ to move through the
parameters of the menu.
• Press the Up ¿ or Down ¯ key to move through
the parameter values.
• Press the Infinity Key ˆ to move backwards
through the levels: parameter to menu; menu to
Home Page.
• Press and hold the Infinity Key ˆ for two seconds
to return to the Home Page.
[COM]
[`rui]
Communications Menu (1 to 2)
[COM] Communications
Comm Instance 1
[`a;ds] Standard Bus Address
[st;2n] Start Zone Address
[nU;2n] Number of Zones
Comm Instance 2
[ad;m] Address Modbus
[bAUd]
Baud Rate Modbus
[`PAr] Parity Modbus
[M;hL] Modbus Word Order
[iP;m] IP Address Mode
[ip;f1] IP Fixed Address (Part 1)
[ip;f2] IP Fixed Address (Part 2)
[ip;f3] IP Fixed Address (Part 3)
[ip;f4] IP Fixed Address (Part 4)
[ip;f5] IP Fixed Address (Part 5)
[ip;f6] IP Fixed Address (Part 6)
[ip;51] IP Fixed Subnet (Part 1)
[ip;52] IP Fixed Subnet (Part 2)
[ip;53] IP Fixed Subnet (Part 3)
[ip;54] IP Fixed Subnet (Part 4)
[ip;s5] IP Fixed Subnet (Part 5)
[ip;s6] IP Fixed Subnet (Part 6)
[ip;g1] IP Fixed Gateway (Part 1)
[ip;g2] IP Fixed Gateway (Part 2)
[ip;g3] IP Fixed Gateway (Part 3)
[ip;g4] IP Fixed Gateway (Part 4)
[ip;g5] IP Fixed Gateway (Part 5)
[ip;g6] IP Fixed Gateway (Part 6)
[mb;e] Modbus TCP Enable
[eip;e] EtherNet/IP Enable
[`ad;d] DeviceNet Address
[bAUd] Baud Rate
[`fC;E] DeviceNet Quick Connect Enable
[p;add] Profibus DP Address
[A;Loc] Profibus DP Address Lock
[`C_f] Display Units
[gLbL]
[`rui]
Global Menu
[C;led] Communications LED Action
[`d;ti] Menu Display Timer
[Usr;s] User Save
[Usr;r] User Restore
[gtw]
[`rui]
Gateway Menu
[gtw] Gateway (1 to 16)
[du;En] Device Enabled
[du;St]
Device Status
[M;oF] Modbus Address Offset
[`oSt] CIP Instance Offset
[Ao;nb] CIP Implicit Output Assembly Member Quantity
[Ai;nb] CIP Implicit Input Assembly Member Quantity
[`S;of] Profibus DP Slot Offset
[`LoC]
[`rui]
Security Setting Menu
[pas;e] Password Enabled
[RloC] Read Lock
[SLoC] Write Security
[loC;l] Locked Access Level
[roll] Rolling Password
[pas;u] User Password
[pas;a] Administrator Password
[ULoC]
[`rui]
Security Setting Menu
[Code] Public Key
[pass] Password
[diAg]
[`rui]
Diagnostics Menu
[``Pn] Part Number
[`rEu] Firmware Revision
[S;bld] Software Build Number
[``Sn] Serial Number
[dAtE] Date of Manufacture
[ip;aC] IP Actual Address Mode
[ip;a1] IP Actual Address Part 1
[ip;a2] IP Actual Address Part 2
[ip;a3] IP Actual Address Part 3
[ip;a4] IP Actual Address Part 4
[ip;a5] IP Actual Address Part 5
[ip;a6] IP Actual Address Part 6
