Watlow EZ-ZONE ® RUI/Gateway • 37 • Chapter 5 Networking with a Gateway
Network Status
Indicator State Summary Requirement
Steady Off
Not powered,
no IP address
If the device does not
have an IP address (or
is powered off), the net-
work status indicator
shall be steady off.
Flashing Green No connections
If the device has no es-
tablished connections,
but has obtained an IP
address, the network
status indicator shall
be flashing green.
Steady Green Connected
If the device has at
least one established
connection (even to the
Message Router), the
network status indi-
cator shall be steady
green.
Flashing Red
Connection
timeout
If one or more of the
connections in which
this device is the target
has timed out, the net-
work status indicator
shall be flashing red.
This shall be left only
if all timed out connec-
tions are reestablished
or if the device is reset.
Steady Red Duplicate IP
If the device has de-
tected that its IP ad-
dress is already in use,
the network status in-
dicator shall be steady
red.
Flashing Green / Red Self-test
While the device is
performing its power
up testing, the network
status indicator shall
be flashing green / red.
Module Status
Indicator State Summary Requirement
Steady Off No power
If no power is supplied
to the device, the module
status indicator shall be
steady off.
Steady Green
Device
operational
If the device is operat-
ing correctly, the module
status indicator shall be
steady green.
Flashing Green Standby
If the device has not been
configured, the module
status indicator shall be
flashing green.
Flashing Red Minor fault
If the device has detected
a recoverable minor fault,
the module status indica-
tor shall be flashing red.
NOTE: An incorrect or
inconsistent configuration
would be considered a mi-
nor fault.
Module Status (cont.)
Indicator State Summary Requirement
Steady Red Major fault
If the device has detected
a non-recoverable major
fault, the module status
indicator shall be steady
red.
Flashing Green / Red Self-test
While the device is per-
forming its power up
testing, the module status
indicator shall be flashing
green / red.
Link Status
Indicator State Summary Requirement
Steady Off
Not powered,
unknown link
speed
If the device cannot
determine link speed
or power is off, the net-
work status indicator
shall be steady off.
Red
Link speed = 10
Mbit
If the device is commu-
nicating at 10 Mbit, the
link LED will be red..
Green
Link speed =
100 Mbit
If the device is com-
municating at 100 Mbit,
the link LED will be
green.
Activity Status
Indicator State Summary Requirement
Flashing Green
Detects activ-
ity
If the MAC detects activ-
ity, the LED will be flash-
ing green.
Red
Link speed =
10Mbit
If the MAC detects a col-
lision, the LED will be
red.
Using Profibus DP
Communications To/From Third Party Device:
The RUI/GTW equipped with the Profibus DP proto-
col supports cyclic (DP-V0) and acyclic (DP-V1) com-
munications. For your reference, cyclic communica-
tions implies that a set of defined parameters (user
configured as it relates to the RUI/GTW) are periodi-
cally read and or written. The frequency or period of
the read/write operations is determined (setup) via
the Master on the network. You can configure the
cyclic parameter set by installing the software (Pro-
fibus GSD Editor for EZ-ZONE Products) which can
be found on the CD that came with the product (Con-
troller Support Tools) or by clicking on the link below
where it can be downloaded free of charge. Once the
GSD (Generic Station Description) file is created,
simply upload it to the Master device.
http://www.watlow.com/literature/pti_search.cfm?dltype=4
Acyclic communications will read and or write data
on demand and is based on the Slot Offset and the
specific index for any given parameter. Most of the
discussion that follows is related to acyclic communi-
cations.
