Watlow EZ-ZONE ® RUI/Gateway • 13 • Chapter 3 Keys and Displays
Programming the EZ Key Using an RUI
The following examples show how to program the EZ
Key to start and stop a profile using PM, RM and ST
family controllers.
Note:
This functionality is embedded in the configuration
of the control, therefore, any "EZ" Function Key
from any RUI pointing to the programmed control
will assume the programmed function.
Using the RUI with PM Family Controllers
Note:
The steps shown below were created using PM
firmware version 11.00. Slight differences may ex-
ist if your controller has a different version. The
firmware version can be found by cycling power
to the controller (first numerical value displayed
in the upper display) or by navigating to the revi-
sion [`reu] prompt found in the Diagnostic Menu
[diag]
in the Factory Page
1. Go to the Setup Page from the Home Page, press
both the Up ¿ and Down ¯ keys for six seconds.
[``Ai]
will appear in the upper display and [`Set]
will appear in the lower display.
2. Press the Up ¿ or Down ¯ key until [`FUn] ap-
pears in the upper display and [`SEt] will appear in
the lower display.
3. Press the Advance Key ‰ once. [high] will appear
in the upper display and [`LEu] (high or low) will
appear in the lower display. Select whether a high
state or a low state will start the profile.
3. Press the Up ¿ or Down ¯ key to scroll through
the functions that can be assigned to the EZ Key.
When [P;StS] (Profile Start/Stop) appears in the up-
per display and [``Fn] appears in the lower display,
press the Infinity Key once to select that function
and move to the [``F;i] (Function Instance equals
Profile 1, 2, 3 or 4) parameter.
4. Press the Up ¿ or Down ¯ key to select the profile
of choice.
5. Press the Infinity Key ˆ once to return to the sub-
menu, twice to return to the Home Page.
Using the RUI with RM Family Controllers
Note:
The steps shown below were created using RM
firmware version 6.00. Slight differences may exist
if your controller has a different version. The firm-
ware version can be found by navigating to the revi-
sion [`reu] prompt found in the Diagnostic Menu
[diag]
in the Factory Page.
1. Go to the Setup Page from the Home Page, press
both the Up ¿ and Down ¯ keys for six seconds.
[``Ai]
will appear in the upper display and [`Set]
will appear in the lower display.
2. Press the Up ¿ or Down ¯ key until the Action
prompt [`ACt] appears in the upper display and
[`SEt]
will appear in the lower display.
3. Press the Advance Key ‰ once and select the Action
instance (1-8) using the Up ¿ or Down ¯ key. Upon
entry, the upper display will show [```1] and the
lower display will show [`ACt].
4. Press the Advance Key ‰ once and then using the
Up ¿ or Down ¯ key to select Profile Start/Stop
[p;sts]
as the Function [``Fn].
5. Press the Advance Key ‰ once and then using the
Up ¿ or Down ¯ key select the Function Instance
[``F;i]
(Function Instance equals Profile 1, 2, 3...25).
6. Press the Advance Key ‰ once to define the source
of this Action by using the Up ¿ or Down ¯ key to
select the Function Key [`Fun] as the Source Func-
tion [SFn;a].
7. Press the Advance Key ‰ once and then using the
Up ¿ or Down ¯ key select the Source Instance
[`Si;a]
(Source Instance in this case equals EZ-Key
1 or 2.
8. Press the Advance Key ‰ once and then using the
Up ¿ or Down ¯ key select the Source Zone [`S2;a]
(Source Zone equals 0 -16).
Note:
Zone 0 represents the current module being config-
ured while in this example, this selection represents
the module in which the profile will run.
9. Press the Advance Key ‰ once and then using the
Up ¿ or Down ¯ key select the Level [`Leu]
desired to trigger the Action, high [high] or low
[low]
.
10. Press the Infinity Key ˆ three times to return to
the Home Page.
Using the RUI with ST Family Controllers
Note:
The steps shown below were created using PM
firmware version 8.00. Slight differences may ex-
ist if your controller has a different version. The
firmware version can be found by cycling power
to the controller (first numerical value displayed
in the upper display) or by navigating to the revi-
sion [`reu] prompt found in the Diagnostic Menu
[diag]
in the Factory Page
1. Go to the Setup Page from the Home Page, press
both the Up ¿ and Down ¯ keys for six seconds.
[``Ai]
will appear in the upper display and [`Set]
will appear in the lower display.
2. Press the Up ¿ or Down ¯ key until [`FUn] ap-
pears in the upper display and [`SEt] will appear in
the lower display.
3. Press the Advance Key ‰ once. [```1] will appear
in the upper display and [`FUn] will appear in the
lower display. At this time select instance 1.
