RMC CIP T to O Implicit Assemblies
Assembly
Members
Assembly
Class, Instance,
Attritbute
RM Module
Data Type
Parameter
Parameter
Class, Instance,
Attritbute
PLC
Data Type
0
Cannot be changed
Binary
Device Status
none
DINT
1
0x77, 0x02, 0x01
DINT
Analog Input 1, Analog Input Value (filtered)
0x68, 0x01, 0x01
REAL
2
0x77, 0x02, 0x02
DINT
Analog Input 1, Input Error
0x68, 0x01, 0x02
DINT
3
0x77, 0x02, 0x03
DINT
Analog Input 2, Analog Input Value (filtered)
0x68, 0x02, 0x01
REAL
4
0x77, 0x02, 0x04
DINT
Analog Input 2, Input Error
0x68, 0x02, 0x02
DINT
5
0x77, 0x02, 0x05
DINT
Analog Input 3, Analog Input Value (filtered)
0x68, 0x03, 0x01
REAL
6
0x77, 0x02, 0x06
DINT
Analog Input 3, Input Error
0x68, 0x03, 0x02
DINT
7
0x77, 0x02, 0x07
DINT
Analog Input 4, Analog Input Value (filtered)
0x68, 0x04, 0x01
REAL
8
0x77, 0x02, 0x08
DINT
Analog Input 4, Input Error
0x68, 0x04, 0x02
DINT
9
0x77, 0x02, 0x09
DINT
Alarm 1, Alarm State
0x6D, 0x01, 0x09
DINT
10
0x77, 0x02, 0x0A
DINT
Alarm 2, Alarm State
0x6D, 0x02, 0x09
DINT
11
0x77, 0x02, 0x0B
DINT
Alarm 3, Alarm State
0x6D, 0x03, 0x09
DINT
12
0x77, 0x02, 0x0C
DINT
Alarm 4, Alarm State
0x6D, 0x04, 0x09
DINT
13
0x77, 0x02, 0x0D
DINT
Alarm 5, Alarm State
0x6D, 0x05, 0x09
DINT
14
0x77, 0x02, 0x0E
DINT
Alarm 6, Alarm State
0x6D, 0x06, 0x09
DINT
15
0x77, 0x02, 0x0F
DINT
Alarm 7, Alarm State
0x6D, 0x07, 0x09
DINT
16
0x77, 0x02, 0x10
DINT
Alarm 8, Alarm State
0x6D, 0x08, 0x09
DINT
17
0x77, 0x02, 0x11
DINT
Control Loop 1, Output Power
0x97, 0x01, 0x0F
REAL
18
0x77, 0x02, 0x12
DINT
Control Loop 2, Output Power
0x97, 0x02, 0x0F
REAL
19
0x77, 0x02, 0x13
DINT
Control Loop 3, Output Power
0x97, 0x03, 0x0F
REAL
20
0x77, 0x02, 0x14
DINT
Control Loop 4, Output Power
0x97, 0x04, 0x0F
REAL
21
0x77, 0x02, 0x15
DINT
None Specified
- - - -
- - - -
22
0x77, 0x02, 0x16
DINT
None Specified
- - - -
- - - -
23
0x77, 0x02, 0x17
DINT
None Specified
- - - -
- - - -
24
0x77, 0x02, 0x18
DINT
None Specified
- - - -
- - - -
25
0x77, 0x02, 0x19
DINT
None Specified
- - - -
- - - -
26
0x77, 0x02, 0x1A
DINT
None Specified
- - - -
- - - -
27
0x77, 0x02, 0x1B
DINT
None Specified
- - - -
- - - -
28
0x77, 0x02, 0x1C
DINT
None Specified
- - - -
- - - -
29
0x77, 0x02, 0x1D
DINT
None Specified
- - - -
- - - -
30
0x77, 0x02, 0x1E
DINT
None Specified
- - - -
- - - -
31
0x77, 0x02, 0x1F
DINT
None Specified
- - - -
- - - -
32
0x77, 0x02, 0x20
DINT
None Specified
- - - -
- - - -
33
0x77, 0x02, 0x21
DINT
None Specified
- - - -
- - - -
34
0x77, 0x02, 0x22
DINT
None Specified
- - - -
- - - -
35
0x77, 0x02, 0x23
DINT
None Specified
- - - -
- - - -
36
0x77, 0x02, 0x24
DINT
None Specified
- - - -
- - - -
37
0x77, 0x02, 0x25
DINT
None Specified
- - - -
- - - -
38
0x77, 0x02, 0x26
DINT
None Specified
- - - -
- - - -
39
0x77, 0x02, 0x27
DINT
None Specified
- - - -
- - - -
40
0x77, 0x02, 0x28
DINT
None Specified
- - - -
- - - -
CIP Implicit Assembly
Target (
RMC
) to Originator (Master)
Note:
When configuring the gateway T to O assembly size for the RMC, the maximum size is using the RUI is 20.
The graphic above shows 41 members where the first member (0 - Device Status) is implied. When configur-
ing the Master assembly size, Device Status cannot be omitted.
