Watlow EZ-ZONE ® RUI/Gateway • 12 • Chapter 3 Keys and Displays
Changing the Position of a Controllers Op-
erations Page and or Profiling Page in the
Lockout Menu
To change the position of the Operations Page or Pro-
filing Page in the Lockout Menu, you must go to the
Lock Operations Page parameter [LoC;O] or Lock Pro-
filing Page parameter [LoC;P] in the Lockout Menu in
the Factory Page.
• To go to the Factory Page from the Home Page,
press both the Advance ‰ and Infinity ˆ keys
for six seconds. [CUSt] will appear in the Upper
Display and [FCty] will appear in the Lower
Display.
• Press the Up ¿ or Down ¯ key to move to the
Lockout Menu [`LoC].
• Press the Advance Key ‰ to select a parameter.
• Press the Up ¿ or Down ¯ key to change the
parameter value. The value you select (1, 2 or
3) will determine the position of the Operations
Page or Profiling Pages in the Lockout Menu in
the RUI Page.
• Press the Infinity Key ˆ to move backwards
through the levels: parameter to menu; menu to
Home Page.
• Press and hold the Infinity Key ˆ for two seconds
to return to the Home Page.
Note:
[rLoC] and [SLoC] settings of the RUI will always
take precedence over any other individual controller
settings. In other words, if an RUI is on a network
with multiple PM controllers where all of the PM
controllers have [SLoC] set to 0 (not writable) and
the RUI has [SLoC] set to 5, all writable param-
eters in all PM controllers can be written to via the
RUI. Conversely, if all PM controllers have [SLoC]
set to 5 and the RUI has it set to 0 all of the PM
controllers will be write protected. If it is required
that protection for any given controller not be over-
ridden by the RUI turn to the Features section of
the controller user manual and find the section en-
titled "Using Password Security".
Example 1
The operator wants to read all the menus and not al-
low any parameters to be changed.
In the RUI Page, Lockout Menu, set Read Lock
[rLoC]
to 5 and Set Lock [SLoC] to 0.
Example 2
The operator wants to read and write to the Home
Page and Profiling Page, and lock all other pages and
menus.
In the RUI Page, Lockout Menu, set Read Lock
[rLoC]
to 2 and Set Lock [SLoC] to 2.
In the Factory Page, Lockout Menu, set Lock Op-
erations Page [LoC;O] to 3 and Lock Profiling Page
[LoC;P]
to 2.
Example 3
The operator wants to read the Operations Page,
Setup Page. Profiling Page, Diagnostics Menu, Lock
Menu, Calibration Menu and Custom Menus. The op-
erator also wants to read and write to the Home Page.
In the RUI Page, Lockout Menu, set Read Lock
[rLoC]
to 1 and Set Lock [SLoC] to 5.
In the Factory Page, Lockout Menu, set Lock Op-
erations Page [LoC;O] to 2 and Lock Profiling Page
[LoC;P]
to 3.
