Watlow EZ-ZONE ® RUI/Gateway • 27 • Chapter 4 RUI Page
Display
Parameter name
Description
Range Default
Modbus
Relative Ad-
dress
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter ID
Data
Type
& Read/
Write
[ULoC]
[`rui]
Unlock Security Setting Menu
[Code]
[CodE] Security Setting
Public Key
If Rolling Password turned
on, generates a random
number when power is
cycled. If Rolling Password
is off fixed number will be
displayed.
Customer Specific 0 - - - - - - - - - - - - 3020 uint
R
[pass]
[PASS] Security Setting
Password
Number returned from cal-
culation found in Features
section under Password
Security.
-1999 to 9999 0 - - - - - - - - - - - - 3022 int
RW
[diAg]
[`rUi]
Diagnostics Menu
[``Pn]
[ Pn] Diagnostics Menu
Part Number
Display the RUI/GTW part
number.
15 characters None - - - - 0x65 (101)
1
9
5 1009 string
R
[`rEu]
[ rEu] Diagnostics Menu
Software Revision
Display the RUI/GTW firm-
ware revision number.
1 to 10 - - - - 4 0x65 (101)
1
3
6 1003 dint
R
[S;bLd]
[ S.bLd] Software Build
View the software build
number.
0 to 2, 147,483,647 - - - - 8 0x65 (101)
1
5
- - - - 1005 dint
R
[``Sn]
[ Sn] Serial Number
View the controller serial
number.
0 to 2, 147,483,647 - - - - 12 0x65 (101)
1
7
- - - - 1032 dint
R
[dAtE]
[dAtE] Date of Manufacture
View the controller manu-
facture date.
0 to 2, 147,483,647 - - - - 14 0x65 (101)
1
8
- - - - 1008 dint
R
[iP;AC]
[iP.AC] Diagnostics Menu
IP Actual Address Mode
View the addressing mode
of the gateway in slot B of
this RUI.
[dhCP] DHCP
[F;Add] Fixed Ad-
dress
DHCP - - - - - - - - - - - - 17013 uint
R
[iP;A1]
[iP.A1] Diagnostics Menu
IP Actual Address Part 1
View or change the first
part of the IP address of
the gateway in slot B of this
RUI..
0 to 255 None - - - - - - - - - - - - 17014 uint
R
[iP;A2]
[iP.A2] Diagnostics Menu
IP Actual Address Part 2
View or change the second
part of the IP address of
the gateway in slot B of this
RUI..
0 to 255 None - - - - - - - - - - - - 17015 uint
R
[iP;A3]
[iP.A3] Diagnostics Menu
IP Actual Address Part 3
View or change the third
part of this controller's IP
address.
0 to 255 None - - - - - - - - - - - - 17016 uint
R
