ST3000 Series Hardware Manual
1-4
ST Interfaces
(1) USB Host Interface
(2) CF Card Interface
Only the ST-3400/3500 Series are supported.
(3) Serial Interface (COM1)
(4) Serial Interface (COM2)
(except for AST-3211A and AST-3302B)
(5) Serial Interface (COM2)
(AST-3211A and AST-3302B only)
PLC Interfaces
(6) RS-232C Port
(7) RS-422 Port
(8) RS-485 Port
(9) Programing Console Port
(10) PG Port
(4)
(9)
(9)
(7)
(9)
(7)
COM Port
Conversion
Adapter
CA3-ADPCOM-01
Mitsubishi PLC
FX-Series Connection Cable
CA3-CBLFX/1M-01
CA3-CBLFX/5M-01
Mitsubishi PLC
A-Series Connection Cable
CA3-CBLA-01
RS-422 Cable
CA3-CBL422/5M-01
RS-422 Cable
CA3-CBL422-01
2 Port Adapter Cable
CA3-MDCB11
Multi-Link Cable
CA3-CBLMLT-01
(8)
MPI Cable
CA3-MPI-PGN-PFE
CA3-MPI-PG1-PFE
Mitsubishi PLC A , QnA,
FX Series' 2 Port Adapter II
GP070-MD11
Host Controller
PLC etc.
(8) (5)
PROFIBUS Cable
(Prepared by user)
(8)
MPI Cable
ST03-A2B-MPI21-PEE
