AFL2-W15A-N270/L325 Panel PC
Page 71
3.3.5.2 Power Configuration
The Power Configuration menu (BIOS Menu 10) allows the advanced power
management options to be configured.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Power Exit
Power Button Mode
[On/Off]
Resume On PCIE PME#
[Enabled]
Resume On Ring [Disabled]
Resume On Touch Panel [Disabled]
RTC Resume [Disabled]
If the AT/ATX jumper
been set to AT mode
this item will be
changed to "power on"
automatically
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 10: Power Configuration
Î Power Button Mode [On/Off]
Use the Power Button Mode BIOS to specify how the power button functions.
Î
On/Off D EFAULT
When the power button is pressed the system is either
turned on or off
Î
Suspend When the power button is pressed the system goes into
suspend mode
Î Resume on PCIE PME# [Enabled]
Use the Resume on PCIE PME# BIOS option to enable activity on the PCIE PME (power
management event) controller to rouse the system from a suspend or standby state.
Î
Disabled Wake event not generated by PCIE PME controller
activity
Î
Enabled D EFAULT
Wake event generated by PCIE PME controller activity
