IEI Integration AFL2-W15A-N270_W15A-L325 v1.01 - Manual (Page 20)

AFL2-W15A-N270/L325 Panel PC
Page 8
SPECIFICATIONS AFL2-W15A-N270 AFL2-W15A-L325
Bluetooth Bluetooth V2.1+EDR Bluetooth V2.1+EDR
HSUPA Optional HSUPA Mobile Module (supports
GSM 850, EGSM 900, DCS 1800 & 1900)
Optional HSUPA Mobile Module
(supports GSM 850, EGSM 900, DCS
1800 & 1900)
RFID Reader
(Optional)
EM 125 KHz card reader or
Mifare 13.56 MHz card reader
(Detailed specifications are provided in Section 2.11)
Power Adapter 60 W
90-246 VAC input 50/60 Hz
12 V DC output
84 W
90-246 VAC input 50/60 Hz
12 V DC output
Power
Consumption
51 W 68 W
Mounting Feature VESA 100 mm x 100 mm
Operating Temp. -10ºC ~ 50ºC
Dimension
(WxHxD)
400 mm x 67 mm x54 mm
Net/Gross Weight 3.8 kg
Front Panel
Protection
IP64 compliant
EMC and Safety CE, FCC, CB, CCC
Table 1-2: System Specifications
