AFL2-W15A-N270/L325 Panel PC
Page 36
2.8 Mounting the System
WARNING!
The panel PC is very heavy. Two or more people should mount the
panel PC. Dropping or bumping the panel PC during installation can
cause serious or irreparable damage to the panel PC.
The following installation options are available:
ƒ Arm mounting
ƒ Panel mounting
ƒ Stand mounting
ƒ Wall mounting
The installation instructions are included with the stand, arm or mount.
2.8.1 Arm Mounting
The AFL2-W15A-N270/L325 is VESA (Video Electronics Standards Association)
compliant and can be mounted on an arm with a 100 mm interface pad. To mount the
AFL2-W15A-N270/L325 on an arm, please follow the steps below.
Step 1: The arm is a separately purchased item. Please correctly mount the arm onto
the surface it uses as a base. To do this, refer to the installation documentation
that came with the mounting arm.
NOTE:
When purchasing the arm please ensure that it is VESA compliant and
that the arm has a 100 mm interface pad. If the mounting arm is not
VESA compliant it cannot be used to support the
AFL2-W15A-N270/L325.
