3.3.4 Hardware Health Configuration
The Hardware Health Configuration menu (BIOS Menu 7) shows the operating
temperature, fan speeds and system voltages.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Power Exit
Hardware Health Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU Temperature
:61ºC/141ºF
System Temperature :64ºC/147ºF
SYS Fan Speed
:2509 RPM
CPU Core
:0.880 V
1.1V :1.088 V
3.3V :3.312 V
5V :4.945 V
12V :11.840 V
1.8V :1.840 V
1.2V :1.184 V
5V Dual :4.999 V
VBAT :3.504 V
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 7: Hardware Health Configuration
Î Monitored Values
The following system parameters and values are shown. The system parameters that are
monitored are:
ƒ The following system temperatures are monitored:
o CPU temperature
o System temperature
ƒ The following fan speeds are monitored:
o SYS fan speed
ƒ The following core voltages are monitored:
o CPU core
o 1.1V
o 3.3V
