AFL2-W15A-N270/L325 Panel PC

Page 30

AFL2-W15A-L325

Figure 2-12: COM3 Pin 9 Setting Jumper Locations

2.7.6 COM3 RX Function Select Jumper

Jumper Label:

JP8 (AFL2-W15A-N270)

JP11 (AFL2-W15A-L325)

Jumper Type:

8-pin header

Jumper Settings:

See Table 2-10

Jumper Location:

See Figure 2-13

The COM3 RX Function Select jumper sets the communication protocol used by the RX

serial communications port COM3 as RS-232, RS-422 or RS-485. The COM3 RX

Function Select jumper settings are shown in Table 2-10.

JP8 (N270)

JP11 (L325)

Description

Short 1-2

DET BIOS RS-232/422/485

Short 3-4

RS-232 (Default)

Short 5-6

RS-422

Short 7-8

RS-485

Table 2-10: COM3 RX Function Select Jumper Settings
