AFL2-W15A-N270/L325 Panel PC

Page 99

Figure 4-1: Back Cover Retention Screws

4.4 Memory Module Replacement

The flat panel PC has a preinstalled memory module. If the memory module fails, take the

steps below to replace it.

Step 1:

Remove the back cover. See Section 4.3 above.

Step 2:

Locate the memory module on the motherboard of the flat panel PC
