AFL2-W15A-N270/L325 Panel PC
Page 21
Pin Description Pin Description
1 DCD-5 2 DSR-5
3 RXD-5 4 RTS-5
5 TXD-5 6 CTS-5
7 DTR-5 8 RI-5
9 GND 10 GND
11 GND 12 GND
13 DCD-6 14 DSR-6
15 RXD-6 16 RTS-6
17 TXD-6 18 CTS-6
19 DTR-6 20 RI-6
21 GND 22 GND
Two
Serial
Ports
23 GND 24 GND
25 PD7 26 PD6
27 PD5 28 PD4
29 PD3 30 PD2
31 PD1 32 PD0
33 -STB 34 -AFD
35 -ERR 36 -INIT
37 -SLIN 38 -ACK
39 BUSY 40 PE
41 SLCT 42 GND
43 GND 44 GND
45 VCC5 46 VCC12
47 VCC5 48 VCC12
One
Parallel
Port
49 VCC5 50 VCC12
Table 2-3: Slot 3 Pinouts (for Type B Module)
For the dimensions of the Type A and Type B expansion modules, please refer to
Appendix C.
