AFL2-W15A-N270/L325 Panel PC
Page 32
2.7.7 COM3 RS-232/422/485 Serial Port Select Jumper
Jumper Label: JP10 (AFL2-W15A-N270)
JP9 (AFL2-W15A-L325)
Jumper Type: 12-pin header (four 3-pin headers combined)
Jumper Settings: See Table 2-11
Jumper Location: See Figure 2-14
The COM3 RS-232/422/485 Serial Port Select jumper sets the communication protocol
used by the second serial communications port (COM3) as RS-232, RS-422 or RS-485.
The COM3 RS-232/422/485 Serial Port Select settings are shown in Table 2-11.
JP10 (N270)
JP9 (L325)
Description
Short 1-2, 4-5, 7-8, 10-11 RS-232 (Default)
Short 2-3, 5-6, 8-9, 11-12 RS-422/485
Table 2-11: COM3 RS-232/422/485 Serial Port Select Jumper Settings
The COM3 RS-232/422/485 Serial Port Select jumper location is shown in Figure 2-14.
