AFL2-W15A-N270/L325 Panel PC
Page 91
Î DRAM ECC Enable [Enabled]
Use the DRAM ECC Enable option to enable the hardware to report and correct memory
errors and thereby automatically maintain the system.
Î
Disabled System cannot report and correct memory errors
Î
Enabled D EFAULT
System can report and correct memory errors
Î 4-Bit ECC Mode
Use the 4-Bit ECC Mode to enable or disable the 4-Bit ECC mode (a.k.a. CHIPKILL ECC
MODE)
Î
Disabled 4-Bit ECC mode disabled
Î
Enabled D EFAULT
4-Bit ECC mode enabled
Î DRAM SCRUB REDIRECT [Disabled]
Use the DRAM SCRUB REDIRECT option to enable the system to immediately correct
DRAM ECC errors when they occur, even when background scrubbing is on.
Î
Disabled D EFAULT
System cannot immediately correct DRAM ECC errors
Î
Enabled System cannot immediately correct DRAM ECC errors
Î DRAM BG Scrub [Disabled]
Use the DRAM BG Scrub option to enable the system to immediately correct memory
errors so later reads are correct. Doing this while memory is not being used improves
performance.
NOTE:
When the AMD node interleave feature is enabled, BIOS will force
DRAM scrub off.
