WAFER-945GSE 3.5” Motherboard
Page 78
NOTE:
IEI has a wide range of backplanes available. Please contact your
WAFER-945GSE vendor, reseller or an IEI sales representative at
327H312H
[email protected] or visit the IEI website (
328H313H
http://www.ieiworld.com.tw)
to find out more about the available chassis.
5.6.2 Motherboard Installation
To install the WAFER-945GSE motherboard into the chassis please refer to the reference
material that came with the chassis.
5.7 Internal Peripheral Device Connections
5.7.1 Peripheral Device Cables
The cables listed in
850H806H
Table 5-8 are shipped with the WAFER-945GSE.
Quantity Type
1 Keyboard and Mouse cable
2 SATA drive cable
1 Audio cable
1 RS-232 cable
Table 5-8: IEI Provided Cables
Some optional items that can be purchased separately and installed on the
WAFER-945GSE include:
Dual port USB cable
RS-232/422/485 cable
ATX power cable
SATA power cable
