WAFER-945GSE 3.5” Motherboard
Page 5
System Chipset
Northbridge: Intel® 945GSE
Southbridge: Intel® ICH7-M
Memory
One 200-pin SO-DIMM socket supports one 400 MHz or
533 MHz 2.0 GB (max.) DDR2 SDRAM SO-DIMM
CompactFlash® One CompactFlash® Type II socket
Super I/O ITE IT8718
Display
Intel® Generation 3.5 integrated GFX core (133 MHz)
18-bit dual channel LVDS integrated in Intel® 945GSE
Dual-display supported (VGA and LVDS)
BIOS AMI BIOS label
Audio Realtek ALC655 AC'97 codec
LAN Two Realtek RTL8111CP GbE controllers
COM
Five RS-232 serial ports
One RS-232/422/485 serial port
USB2.0
Six USB 2.0 devices supported:
Four by onboard pin-headers
Two by external connectors
SATA Two 3.0 Gb/s SATA drives supported
Keyboard/mouse One internal pin-header connector
Expansion One PCIe mini card (PCIe bus)
Digital I/O
One 8-bit digital input/output connector; 4-bit input/4-bit
output through the ITE IT8718 super I/O
Watchdog Timer
Software programmable 1-255 sec. through the ITE IT8718
super I/O
