NANO-CV-D25501/N26001 EPIC SBC
Page 60
4.6.4 LVDS LCD Installation
The NANO-CV-D25501/N26001 can be connected to a TFT LCD screen through the
LVDS crimp connectors on the board. To connect a TFT LCD to the
NANO-CV-D25501/N26001, please follow the steps below.
Step 1: Locate the connector. The location of the LVDS connector is shown in
Chapter 3.
Step 2: Insert the cable connector. Insert the connector from the LVDS PCB driving
board to the LVDS connector as shown in Figure 4-13. When connecting the
connectors, make sure the pins are properly aligned.
WARNING:
The diagram below is merely for illustration. The configuration and
connection of the cables from the TFT LCD screen being installed may
be different. Please refer to the installation manual that came with the
TFT LCD screen.
