NANO-CV-D25501/N26001 EPIC SBC
Page 8
Specification/Model NANO-CV-D25501/N26001
Expansion
One PCIe Mini card slot with mSATA support (SATA1 and mSATA share
SATA signal)
One PC/104-Plus slot (ISA bus and PCI bus)
Audio
Realtek ALC662 HD Audio codec
One internal audio connector (10-pin box header)
COM
Three RS-232
One RS-422/485
Digital I/O One 8-bit digital input/output connector (4-bit input/4-bit output)
Fan One 3-pin CPU fan connector
Front Panel One 10-pin header (power LED, HDD LED, power button, reset button)
Keyboard/Mouse One internal 6-pin wafer connector
microSD One microSD card slot (for booting up to DOS only)
SATA
Two SATA 3Gb/s ports with 5V power connectors (SATA1 and mSATA
share SATA signal)
USB
Two external USB 3.0 ports
Four USB 2.0 (two external ports, two via pin header)
Power Supply
Max. power input voltage range: 9V~28V
Recommended operating input voltage range: 12V~24V
One internal 4-pin (2x2) power connector
Power Consumption
12V @ 2.1 A (1.86 GHz Intel® Atom™ D2550 CPU with 2 GB 1333 MHz
DDR3 SO-DIMM)
12V @ 1.72 A (1.6 GHz Intel® Atom™ N2600 CPU with 2 GB 1333 MHz
DDR3 SO-DIMM)
Operating
Temperature
D2550: -20ºC ~ 60ºC with free air; -20ºC ~ 70ºC with force air
N2600/N2800: -20ºC ~ 70ºC with free air; -20ºC ~ 75ºC with force air
Storage Temperature
D2550: -30ºC ~ 80ºC
N2600/N2800: -30ºC ~ 85ºC
Humidity (Operating) 5% ~ 95% (non-condensing)
Dimensions 115 mm x 165 mm
