NANO-CV-D25501/N26001 EPIC SBC
Page 16
3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector Type Label
5 V SATA power connectors 2-pin wafer SATA_PWR1,
SATA_PWR2
Audio connector 10-pin header AUDIO1
Backlight inverter connectors 5-pin wafer INV1, INV2
Battery connector 2-pin wafer BAT1
Buzzer connector 2-pin wafer SP1
Digital Input/Output (DIO) connector 10-pin header DIO1
Fan connector 3-pin wafer CPU_FAN1
Front panel connector 10-pin header F_PANEL1
Keyboard and mouse connector 6-pin wafer KB_MS1
LVDS connectors 20-pin/30-pin crimp LVDS1, LVDS2
microSD card slot microSD slot CN11
PC/104-Plus power input connector 3-pin wafer CN3
PC/104-Plus slot 104-pin ISA bus and
120-pin PCI bus
PC104_PLUS1,
CN8
PCIe Mini card slot 52-pin PCIe Mini M_PCIE1
Power connector (9V~28V) 4-pin connector CN2
RS-232 serial port connectors 10-pin header COM1, COM2,
COM3
RS-422/485 serial port connector 4-pin wafer COM4
Serial ATA (SATA) drive connectors 7-pin SATA SATA1, SATA2
SO-DIMM connector SO-DIMM connector DIMM1
USB 2.0 connector 8-pin header USB4
Table 3-1: Peripheral Interface Connectors
