NANO-CV-D25501/N26001 EPIC SBC
Page 94
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
> Intel IGD Configuration
******* Memory Information *******
Memory Frequency
800 MHz(DDR3)
Total Memory 1024 MB
DIMM#1 1024 MB
Config Intel IGD
Settings
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 15: Host Bridge Configuration
5.4.1.1 Intel IGD Configuration
Use the Intel IGD Configuration submenu (BIOS Menu 16) to configure the video device
connected to the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Intel IGD Configuration
Active LVDS1 [Disabled]
IGFX – Boot Type [VBIOS Default]
LVDS1 Panel Type [800x600 LVDS]
Backlight Control [Inverted]
Fixed Graphics Memory Size [128MB]
Enable/Disable LVDS1.
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 16: Intel IGD Configuration
Active LVDS1 [Disabled]
Use the Active LVDS1 option to enable or disable the LVDS1 connector.
