18 sata 6gb/s drive connectors – IEI Integration IMB-Q870-i2 User Manual
Page 52
IMB-Q870-i2 microATX Motherboard
Page 36
Figure 3-18: Power Button Location
3.2.18 SATA 6Gb/s Drive Connectors
CN Label:
S_ATA1, S_ATA2, S_ATA3, S_ATA4
CN Type:
7-pin SATA drive connectors
CN Location:
See Figure 3-19
CN Pinouts:
See Table 3-18
The SATA drive connectors can be connected to SATA drives.
Figure 3-19: SATA 6Gb/s Drive Connector Locations
