IMB-Q870-i2 microATX Motherboard

Page 172

Step 12:

The recovery tool main menu window is shown as below. Press any key to

reboot the system.

S

te

p

0

:

Figure C-21: Press Any Key to Continue

C.3 Auto Recovery Setup Procedure

The auto recovery function allows a system to automatically restore from the factory

default image after encountering a Blue Screen of Death (BSoD) or a hang for around 10

minutes. To use the auto recovery function, follow the steps described in the following

sections.

CAUTION:

The auto recovery function can only run on a Microsoft Windows

system with the following OS versions:

- Windows 2000

- Windows 7

- Windows XP

- Windows XP Embedded

- Windows Vista

- Windows Embedded Standard 7
