IMB-Q870-i2 microATX Motherboard
Page 104
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU_FAN1 Smart Fan Control
[Auto Mode]
Fan start temperature
50
Fan off temperature
40
Fan start PWM
30
Fan slope PWM
1
SYS_FAN1 Smart Fan Control
[Auto Mode]
Fan start temperature
50
Fan off temperature
40
Fan start PWM
30
Fan slope PWM
1
Smart Fan Mode Select
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous
Values
F3 Optimized
Defaults
F4
Save & Exit
ESC Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 14: Smart Fan Mode Configuration
Î CPU_FAN1 Smart Fan Control/SYS_FAN1 Smart Fan Control [Auto Mode]
Use the CPU_FAN1 Smart Fan Control/SYS_FAN1 Smart Fan Control option to
configure the CPU/System Smart Fan.
Î
Auto Mode
D
EFAULT
The fan adjusts its speed using Auto Mode
settings.
Î
Manual Mode
The fan spins at the speed set in Manual Mode
settings.
Î Fan start/off temperature
Use the + or – key to change the Fan start/off temperature value. Enter a decimal
number between 1 and 100.
Î Fan start PWM
Use the + or – key to change the Fan start PWM value. Enter a decimal number between
1 and 128.
