IMB-Q870-i2 microATX Motherboard
Page 105
Î Fan slope PWM
Use the + or – key to change the Fan slope PWM value. Enter a decimal number between
1 and 64.
5.3.11 Serial Port Console Redirection
The Serial Port Console Redirection menu (BIOS Menu 15) allows the console
redirection options to be configured. Console redirection allows users to maintain a
system remotely by re-directing keyboard input and text output through the serial port.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
COM1
Console Redirection [Disabled]
> Console Redirection Settings
COM2
Console Redirection [Disabled]
> Console Redirection Settings
COM3
Console Redirection [Disabled]
> Console Redirection Settings
COM4
Console Redirection [Disabled]
> Console Redirection Settings
COM5
Console Redirection [Disabled]
> Console Redirection Settings
COM6
Console Redirection [Disabled]
> Console Redirection Settings
COM7 (BMC)
Console Redirection [Disabled]
> Console Redirection Settings
iAMT SOL
COM8(Pci Bus0,Dev22,Func3)
Console Redirection [Disabled]
> Console Redirection Settings
Console Redirection
Enable or Disable
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 15: Serial Port Console Redirection
