IMB-Q870-i2 microATX Motherboard

Page 29

Figure 3-11: Front Panel Audio Connector Location

Pin Description

1 LMIC2-L 2 AUD_GND

3 LMIC2-R 4 PRESENCE#

5 LLINE2-R

6 MIC2-JD

7 FRONT-IO

8 NC

9 LLINE2-L 10

LINE2-JD

Table 3-12: Front Panel Audio Connector Pinouts

3.2.11 Front Panel Connector

CN Label:

F_PANEL1

CN Type:

14-pin header

CN Location:

See Figure 3-12

CN Pinouts:

See Table 3-13

The front panel connector connects to the indicator LEDs and buttons on the computer's

front panel.
