5.4.1 PCH-IO Configuration
Use the PCH-IO Configuration menu (BIOS Menu 18) to configure the PCH chipset.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
Auto Power Button Status [Disabled (AT)]
Restore AC Power Loss [Last State]
> PCI Express Configuration
> PCH Azalia Configuration
Power Saving Function(ERP) [Disabled]
PCIEX16 Power
[1 x16 PCIE]
USB SW1 Power [+5V DUAL]
USB SW2 Power [+5V DUAL]
Select AC power state
when power is re-applied
after a power failure.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 18: PCH-IO Configuration
Î Restore on AC Power Loss [Last State]
Use the Restore on AC Power Loss BIOS option to specify what state the system
returns to if there is a sudden loss of power to the system.
Î
Power Off The system remains turned off
Î
Power On The system turns on
Î
Last State D EFAULT The system returns to its previous state. If it was on, it
turns itself on. If it was off, it remains off.
Î Power Saving Function [Disabled]
Use the Power Saving Function BIOS option to enable or reduce power consumption in
the S5 state. When enabled, the system can only be powered-up using the power button.
Î
Disabled D EFAULT Power Saving Function support disabled
