About 963
963 User Guide TC200635 Issue 3 25/03/2008 21
Icon
Supervisors Description
IQL Controller
Non IQ system device
PNC
TONIC
TOPS
XNC
Site Structure
BACnet Lan
Local site
Remote Site
Trend Lan
Unknown Lan
General
Unknown Device
Device Viewer
Displays a tree view of the system to which 963 is connected, enabling the level at which the system is
displayed in the Data Display to be selected. For example, clicking a Lan will display all the points with
labels on that Lan. Icons indicate the type of object. The table below lists the different icons.
Icon
Supervisors Description
921 Supervisor
940 Supervisor
942 Supervisor
943 Supervisor
945 Supervisor
950 Supervisor
963 Supervisor, 962 Supervisor, S2 Supervisor, or ViewPoint
NDP
IQView
