PETracer EML User Manual Chapter 4: Software Overview
LeCroy Corporation
45
4.3 Using the Toolbar
You can use the PETracer application Toolbar as a shortcut to most of the operations
supplied by the menus.
Opens a previously recorded
CATC Trace file.
Edit as text. 
Script Editor. Opens a text editor for editing traffic
generation files (*.peg)
Save As
Allows the open file to be saved
with a new name.
Setup Recording Options
Opens the Recording Options
dialog box. Setup Display Options 
Opens the Display Options dialog box.
Setup Generation Options 
Opens the Generation Options
dialog box.
Start Recording. Real Time Statistics monitor
Opens a window that displays real-time
information.
Stop Recording. Disconnect/Connect Link. 
Click once to break and momentarily later restore
link. Open menu to select either Connect or
Disconnect.
Repeat Upload. 
Opens a dialog box that allows you
to select a portion of memory to
upload from memory, then causes
the Analyzer to re-send the
CATC Trace from the Analyzer
buffer to the host PC.
