PETracer EML User Manual Chapter 12: Address Space
LeCroy Corporation
221
Read Address Space Button
This Read Address Space Button brings up one of two dialogs.
PETrainer EML Read Address Space Dialog
This dialog lets you specify the:
• Address space to be read
• Offset from the beginning of PETrainer memory region
• Size of the data
You cannot specify the Offset and Size for the Configuration Address Space.
The data read can be processed in three ways:
• Displayed in the Configuration Space Editor or the Address Space Editor. To
view the data in these editors, select the Show in Editor radio button option.
• Stored in a file. To store the data into a file, select the Load into File option.
• Compared with previously written file. If you have written memory into the
PETrainer hardware as described above (Write Memory Address Space
Button), then Compare with last written option is enabled.

Note: This option is not available for Configuration Address Space)
In this screenshot Compare with last written option is enabled because the IO
A memory region was previously loaded from the IOa.addr file using Write
Address Space functionality.
