Chapter 8: Recording Options PETracer EML User Manual
114
LeCroy Corporation
Step 4 Assign an action to the selected events by right-clicking each of the
events, selecting Specify Action from the pop-up menu, and assigning
an action such as Trigger, Filter, or Count. Be sure to click the event
itself and not the State cell that it is sitting in (which produces a different
pop-up menu.)
Note: You can also assign actions to events by double-clicking the event and
selecting the Actions page when the Properties dialog box opens.
Step 5 Click OK to close the dialog box. At this point, assuming that the other
options in the Recording Options dialog box have been set (such as the
General page), you can begin the recording by pressing the


Start Recording
button.
