Chapter 10: Traffic Generation PETracer EML User Manual
198
LeCroy Corporation
View Options Menu
The View Options button displays a menu with these options:
Enable Outlining: Adds an expandable/collapsible tree structure to the left side of the
Script Editor showing the hierarchical relationships of the script lines.
Show Line Numbers: Adds line numbers to the left side of the Script Editor window.
Show Tooltips: Allows tooltip popups, which provide descriptions of script keywords
when cursor mouses over a keyword.
Toggle Outlining: Toggles the outline tree between collapsed and expanded states.
10.4 Generation Options Dialogs Overview
The Generation Options dialog box is used to set Config settings in a traffic generation
script (for example, Config = General or Config = Link). This dialog duplicates the
Config script command and is provided as a convenient alternative means of setting this
command in the script.
Note: The Generation Options dialog is subordinate to the script itself, so script
commands override options selected in this dialog box.
Opening the Dialog
To open the Generation Options dialog, select Setup > Generation Options or click 

the Generation Options button
.
Dialog Layout
The Generation Options dialog is organized into five pages: General, Link, Integrity, Flow
Control, and Transactions.
