SierraNet M168 User Manual 39
Application Menu Options Teledyne LeCroy
2.4 Application Menu Options
The following menu options display in the main window:
 File
 Setup
 Analysis
 Navigation
 View
 Window
 Help
2.4.1 File
The File menu has the standard menu options as shown in the following screen capture.
Figure 2.5: File Menu Options
Recording Setting icon. Click to open the Recording Setting
dialog. See
“Recording Settings Pane” on page 53 .
Trigger Filter Settings icon. Click to open the Trigger Filter
Settings dialog. See
“Patterns and Data Capture Setup” on
page 65 .
New Project Click to open a new project
Open Click to open an existing trace or trace files
Save Click to save an existing trace or trace files
Save Project Click to save the current project
Save as Click to save an existing trace or trace files with a different name
or directory.
