The following table describes the Presets that can be used as FC Events.
TABLE 4.2: Events and their Descriptions (FC)
VSAN‐
FCVI(DISCONNECT_RESP) Refer to section “FCVI Patterns” on page 99 .
FCAV
VSAN‐FCAV(Simple)
Refer to section “FCAV Patterns” on page 100 .
VSAN‐FCAV(Extended) Refer to section “FCAV Patterns” on page 100 .
FIP Refer to section “FIP Patterns” on page 100.
MPCP Refer to section “MPCP Pattern” on page 101.
Address Resolution
Protocol Refer to section “Address Resolution Protocol Pattern” on
page 102.
Link Layer Discovery
Protocol Refer to section “Link Layer Discovery Protocol Pattern” on
page 102.
Internet Protocol Refer to section “Internet Protocol Pattern” on page 103.
iSCSI Refer to section “iSCSI Pattern” on page 104.
VLAN Refer to section “VLAN Patterns” on page 106.
ISL Refer to section “ISL Patterns” on page 107.
CN‐Tag Refer to section “CN Tag Patterns” on page 108.
VN‐Tag Refer to section “VN Tag Patterns” on page 108.
Trill Frame Refer to section “LLC” on page 108 .
Protocol Errors Refer to section “Protocol Errors” on page 110 .
Event Description
User Patterns
Most Recent Lists the most recent Events.
New User Group Lists the new user groups.
Presets
Timers/External
Timer
The Event occurs when the timer expires.
Other Trigs Analyzer: the Event occurs when the Analyzer triggers.
External: the Event occurs when the external Trigger In is
asserted.
Basic
Ordered Set
Refer to section “Ordered Set” on page 113 .
Basic Link Service Refer to section “Basic Link Service” on page 117 .
Link Control Frame Refer to section “Link Control Frame” on page 118 .
Link Speed The Event occurs when the link is at the specified speed.
Both Linkup The Event occurs when both ports are out of electric idle.
Event Description
