SierraNet M168 Protocol Analyzer User Manual 197
InFusion Scenarios LeCroy Corporation
Training Sequence Inject Error on Control: Generates Manchester Coding
violation on Control field bits corresponding to the defined
mask: One means violation, and zero means no error.
Inject Error on Status: Generates Manchester Coding
violation on Status field bits corresponding to the defined
mask: One means violation, and zero means no error.
Frame Marker Error: Generates training sequence with an
invalid frame marker.
Recode Manchester Coding: Forces jammer to recalculate
Manchester Coding for each bit of training frame. Refer to
section
“Training Sequence” on page 116
FCP
FCP SCSI Command
Refer to section “SCSI” on page 118 .
FCP Frame Information
Unit Refer to section “FCP Patterns” on page 118 .
SCSI Command Status Refer to section “SCSI” on page 118 .
FCP Task Management Refer to section “FCP Patterns” on page 118 .
ELS
Extended Link Service‐
Request
Refer to section “ELS Patterns” on page 119 .
Extended Link Service‐
Request, Reply Refer to section “ELS Patterns” on page 119 .
Extended Link Service‐
Reply Refer to section “ELS Patterns” on page 119 .
GS
Generic Link Service‐
Request
Refer to section “GS Patterns” on page 120 .
Generic Link Service‐
Request, Reply Refer to section “GS Patterns” on page 120 .
Generic Link Service‐
Reply Refer to section “GS Patterns” on page 120 .
SW
Switch Internal Link ‐
Request
Refer to section “SW Patterns” on page 122 .
Switch Internal Link ‐
Request, Reply Refer to section “SW Patterns” on page 122 .
Switch Internal Link ‐
Reply Refer to section “SW Patterns” on page 122 .
FICON
FICON (Any Data
Information Block Type)
Refer to section “FICON Patterns” on page 123 .
Event Description
