Teledyne LeCroy Connecting Via USB
30 SierraNet M168 User Manual
Figure 1.22: Dynamic IP Setup Success Message
After you see the Warning Message, click Yes
After you see the Success Message, click OK.
Note: You can also click Reset.
1.6 Connecting Via USB
To set up the Analyzer using a USB for the first time:
1. Remove the Analyzer from its shipping container.
2. Insert the Installation CD.
3. Connect the Analyzer to a power outlet using the provided power cord.
4. Connect the USB port to a USB port on the PC using a USB cable.
5. Turn on the rear power switch and the front power switch.
6. Click Next after you see the Add New Hardware Wizard dialog.
7. Follow the Microsoft
® Windows ® on‐screen Plug‐and‐Play instructions for the
automatic installation of the Analyzer as a USB device on your host machine. (The
required USB files are included on the Installation CD.)
8. Click Finish when you see the message that says “Windows has finished installing
the software that your new hardware requires” and the file has been installed in
your host machine.
Note: Do not change from USB to Ethernet, or back, without power cycling the Analyzer.
To connect the Analyzer to a host system via ethernet, refer to “Connecting via Ethernet”
on page 26 .
