Teledyne LeCroy WaveJet 300A Series Remote Control - Manual (Page 43)

WaveJet 300A Remote Control Manual
917976 Rev A
43
Horizontal TDIV
Command/Query
DESCRIPTION The TDIV command sets timebase. The timebase is specified
using any of the following suffixes: NS (nanosecond), US
(microsecond), MS (millisecond), or S (second). If the
specified value exceeds the allowable range, it is
rounded to a permissible value. The TDIV? query returns
the currently set timebase.
COMMAND SYNTAX TDIV
:= Timebase setup parameter. The PROGRAM DATA> format is used, and the suffix is also
valid.
QUERY SYNTAX TDIV?
RESPONSE FORMAT
:= The currently set timebase is identified in
format.
REMARKS
The TDIV command rounds the figure in as follows.
Rounding range Set timebase Note
value <= 500E-12 500 ps/div
500 ps/div is available for
WJ354/352 only
500E-12 < value <= 1E-9 1 ns/div
1 ns/div is available for
WJ354/352/334/332
1E-9 < value <= 2E-9 2 ns/div
2 ns/div is available for
WJ354/352/334/332/324/322
2E-9 < value <= 5E-9 5 ns/div 5 ns/div is available for all models
: :
10 < value <= 20 20 s/div
20 < value 50 s/div
