WaveJet 300A Remote Control Manual
917976 Rev A
31
Math FSRC
Command/Query
DESCRIPTION The FSRC command sets the signal source for FFT. The
FSRC? query returns the currently set signal source for
FFT.
COMMAND SYNTAX FSRC
: = {CH1, CH2, CH3, CH4} (WJ354/334/324/314)
: = {CH1, CH2} (WJ352/332/322/312)
QUERY SYNTAX FSRC?
RESPONSE FORMAT
shows the current signal source for FFT.
REMARKS FSRC command/query reports Device-specific error (DDE)
when math operator is not FFT.
Use MATHS instead of FSRC to select source channels for
math operation other than FFT.
Math FWINDOW
Command/Query
DESCRIPTION The FWINDOW command sets the FFT window. The FWINDOW?
query returns the FFT window.
COMMAND SYNTAX FWINDOW
:= {RECT, VONHANN, FLATTOP}
QUERY SYNTAX FWINDOW?
RESPONSE FORMAT
REMARKS FWINDOW command reports device-specific error (DDE)
when MATH is not FFT.
DISPLAY GRAT
Command/Query
DESCRIPTION The GRAT command selects the graticule type from Grid,
Axis or Frame. The GRAT? query returns the current
graticule type.
COMMAND SYNTAX GRAT
:= {GRID, AXIS, FRAME}
GRID := Select grid graticule type.
AXIS := Select axis graticule type.
FRAME := Select frame graticule type.
QUERY SYNTAX GRAT?
RESPONSE FORMAT
