WaveJet 300A Series
26
917976 Rev A
Data transfer DTPOINTS
Command/Query
DESCRIPTION The DTPOINTS command defines the amount of waveform
data to be transferred. The
DTPOINTS? query returns the defined amount of waveform
data to be transferred.
COMMAND SYNTAX DTPOINTS
:=1 to (waveform data length - DTSTART)
Any values exceeding this range are rounded to the
maximum or minimum permissible value, whichever is
nearest.
QUERY SYNTAX DTPOINTS?
RESPONSE FORMAT
The defined amount of waveform data to be transferred
is identified in . The
format is .
REMARKS (Transfer start address) + (Amount of data to be
transferred) > (Total amount of waveform data)
When DTPOINTS command causes the above case, the
transfer start address is rounded to a permissible
value.
Data transfer DTSTART
Command/Query
DESCRIPTION The DTSTART command defines the transfer start address
for waveform data transfer.
The DTSTART? query returns the defined transfer start
address.
COMMAND SYNTAX DTSTART
:=0 to (waveform data length - 1)
Any values exceeding this range are rounded to the
maximum or minimum permissible value, whichever is
nearest.
QUERY SYNTAX DTSTART?
RESPONSE FORMAT
The defined start address for waveform data transfer
is identified in . The format is Response Data>.
REMARKS (Transfer start address) + (Amount of data to be
transferred) > (Total amount of waveform data)
When DTSTART command causes the above case, the amount
of data to be transferred is rounded to a permissible
value.
