WaveJet 300A Remote Control Manual
917976 Rev A
13
2.16 Response to the identification common query, *IDN?
See the list of commands.
2.17 Size of protected user data storage area if the *PUD command and *PUD? query are
implemented
Not implemented.
2.18 Size of resource description if the *RDT command or *RDT? query are implemented.
Not implemented.
2.19 States affected by *RST, *LRN?, *RCL, and *SAV
Table 2-8. List of states affected
Name State
*RST Same as Recall Default Setup
*LRN Not implemented
*RCL Same as Recall Setup
*SAV Same as Save Setup
2.20 Scope of self-test performed by the *TST? query
The Acquisition Memory test is conducted.
2.21 Additional status data structures used in the device’s status reporting
Status Byte Register
Table 2-9. Model of Status Byte Register
Bit Definition Implemented?
7 Device-Defined Summary Message No (always zero)
6 Master Summary Status Yes
5 Standard Event Status Bit (ESB) Summary Message Yes
4 MAV Queue Summary Message Yes (only GPIB)
3 Device-Defined Summary Message No (always zero)
2 Device-Defined Summary Message No (always zero)
1 Device-Defined Summary Message No (always zero)
0 Trigger Event Status Bit (TESB) Summary Message Yes
Service Request Enable Register
An application programmer can select which summary messages in the Status Byte Register may cause
service requests.
