B-100 HDMATRIX Installation and Users Manual 4X4 & 8X8
pg.8
3.2 CONNECTIONS
3.2.1 Basic Connections
HDMI Sources
• Blu-ray /DVD Player
• Game Console
• Cable/Sat HD DVR
• PC
Video Displays
• HD Flat-Panel
• HD Projector
• HD Flat Panel
• HDMI Extender
Control Devices
• IR Receiver
• Home Automation System
Examples
HDTV
Home AutomaƟon
HDTV
HDTV
HDMI Extender
Receiver
HDMI Extender
TransmiƩer
HD Projector
Game
Console
Blu-ray/DVD
Player
Cable/Sat
HD DVR
IR Receiver
PC
