B-100 HDMATRIX Installation and Users Manual 4X4 & 8X8

© 2011 Binary

pg.13

Embedded EDID Resolution

Color Depth Audio

1

1080p@60Hz

24-Bit

7.1ch

2

1080p@60Hz

24-Bit

2ch

3

1080p@60Hz

24-Bit 3D

7.1ch

4

1080p @60Hz

24-Bit 3D

2ch

5

1080p@60Hz

36-Bit 3D

7.1ch

6

1080p@60Hz

36-Bit 3D

2ch

7

1080i@60Hz / 720p@60Hz

24-Bit

7.1ch

8

1080i@60Hz/ 720p@60Hz

24-Bit

2ch

4.2.1.1 Setting EDID for Single Input

4.2.1.2 Setting EDID for All Inputs

Example: Input =1 Embedded EDID=4

Display Readout (Example)

1.

Press DEFAULT

E-

2.

Press Number Key (1-8) to select one Embedded

EDID

4A

3.

Press INPUT

4A

4.

Press Number Key (1-8) to select the Input to

which the EDID is applied

41

5.

Press ENTER

(success)

(fail)

--

FF

Example: Input=All Embedded EDID=4

Display Readout (Example)

1. Press DEFAULT

E-

2. Press ALL to select all Inputs

E-

3. Press Number Key (1-8) to select Embedded EDID

4A

4. Press ENTER

(success)

(fail)

--

FF
