B-100 HDMATRIX Installation and Users Manual 4X4 & 8X8

pg.14

4.2.2 Learning EDID

For more advanced EDID configuration, learning can be used to assign EDIDs. When used

,the EDID from a particular display is assigned to a particular source or all sources. This

is useful when the system contains a display that may not output the highest resolution

available from the sources.

When to Use Learned EDIDs

• An older display does not work properly with any of the embedded EDIDS.

• When the source is a PC, it may be necessary to use a learned EDID.

• Learning EDID to a Single Input.

Example: Input =1 EDID Learned from Output 4

Display Readout (Example)

1. Press LEARN

L

.

-

.

2. Press OUTPUT

1A

3. Press Number key (1-8) to select the Output the

EDID is learned from

14

4. Press INPUT

L-

5. Press Number Key (1-8) to select the Input to

which the EDID is applied

1A

6. Press ENTER

(success)

(fail)

--

FF

Example: Input=All EDID Learned from Output 4

Display Readout (Example)

1. Press LEARN

L

.

-

.

2. Press OUTPUT
3. Press Number Key (1-8) to select the Output the

EDID is learned from

4

4. Press ENTER

(success)

(fail)

--

FF

4.2.2.1 Learning EDID to All Inputs
Note that learning the EDID for a display to all sources is the same as using Auto EDID.
