Front and rear panel – Staub Electronics B-100-HDMATRIX-4X4 BINARY - HDMI 4X4 MATRIX SWITCH WITH HDMI OUTPUTS User Manual
Page 5
B-100 HDMATRIX Installation and Users Manual 4X4 & 8X8
© 2011 Binary
pg.5
1
2
3
4
5
1
2
3
4
5
2. FRONT AND REAR PANEL
2.2 Front Panel B-100-HDMatrix-8x8
2.1 Front Panel B-100-HDMatrix-4x4
1. Power: Power ON/OFF switch
2. Source Status (LED on = Source is ON and sending a signal)
3. Output: Displays the last selected Output
4. Input: Displays the last selected Input
5. IR Receiver Window
1. Power: Power ON/OFF switch
2. Source Status (LED on = Source is ON and sending a signal)
3. Output: Displays the last selected Output
4. Input: Displays the last selected Input
5. IR Receiver Window
