B-100 HDMATRIX Installation and Users Manual 4X4 & 8X8

© 2011 Binary

pg.17

5.1.2 Turn Off (Mute) Outputs

5.1.3 Display Status

5.1.4 Resetting to Factory Defaults

This procedure resets the B-100-HDMATRIX to factory defaults:

EDIDs - 1080i Stereo (embedded 8), I/O - All Outputs set to Input 1, DHCP (8x8 only) - Enabled.

Note that resetting factory defaults can take up to 2 minutes to complete.

Mute one Output Example: Output=1

Display Readout (Example)

1. Press OUTPUT

--

2. Press Number Key (1-8) to select Output

1-

3. Press OUTPUT OFF

10

4. Press ENTER

10

Mute All Outputs

Display Readout (Example)

1. Press OUTPUT

--

2. Press ALL to select All Outputs

A-

3. Press OUTPUT OFF

A0

4. Press ENTER

40

Example: Input=3

Display Readout (Example)

Example Out-

put=3, Input=4

Example Out-

put=3 Muted

1. Press STATUS

--

--

2. Press OUTPUT

--

--

3. Press Number Key (1-8) to select one Output

3-

3-

4. Press ENTER

34

30

Display Readout

(Example)

1. Press DEFAULT

E-

2. Press DEFAULT

--

3. Press DEFAULT

--

4. Press DEFAULT

DD

5. Press ENTER

D-
