B-100 HDMATRIX Installation and Users Manual 4X4 & 8X8

pg.4

1. OVERVIEW

Welcome to Binary™ - This product is engineered to provide years of exceptional

reliability. Binary™ is one of the most highly regarded brands available today and

stands committed to providing customers with the highest degree of quality and

service in the industry.

The B-100-HDMATRIX-4x4 and B-100-HDMATRIX-8x8 are state-of-the-art HDMI switchers

providing true Matrix Routing for HDMI signals. With features such as HDMI 1.4a 3D

support, sophisticated EDID handling, IR, RS232 and Ethernet (8x8 only) control, they

are ideal for residential and commercial media distribution systems.

1.1 FEATURES

· (4) HDMI Sources by (4) HDMI Outputs {B-100-HDMATRIX-4x4}
· (8) HDMI Sources by (8) HDMI Outputs {B-100-HDMATRIX-8x8}
· Outputs can show the same or different sources simultaneously
· Video resolutions up to 1080p/60 with 36bit color
· Digital Audio up to 7.1 Channels

─ Dolby TrueHD

─ Dolby Digital Plus

─ DTS-HD Master

─ DTS-HD

─ Dolby Digital EX

─ DTS-ES

─ Dolby Digital

─ DTS

─ LPCM

· Support for HDMI 1.4a 3D formats
· Sophisticated EDID handling including Embedded, Learned and Auto modes
· HDMI or DVI with adapter (not included)
· IR Control from integrated receiver or 3.5mm input
· Home Automation Control via IR, RS-232 and Ethernet (8x8 only)
· PC Setup and Configuration
· HDCP 2.0 Compliant
· CEC Compliant

1.2 PACKAGE CONTENTS

(1) B-100-HDMATRIX-4x4 or B-100-HDMATRIX-8x8

(2) Rack ears for mounting

(1) IR Remote

(1) Power supply

• B-100-HDMATRIX-4x4, 5V 4A

• B-100-HDMATRIX-8x8, 12V 5A

(1) IR Adapter for Control Systems

(1) User Manual

(1) CD Rom containing documentation and software
