Staub Electronics B-100-HDMATRIX-4X4 BINARY - HDMI 4X4 MATRIX SWITCH WITH HDMI OUTPUTS User Manual
Page 6
B-100 HDMATRIX Installation and Users Manual 4X4 & 8X8
pg.6
2.4 Rear Panel B-100-HDMATRIX-8x8
2.3 Rear Panel B-100-HDMATRIX-4X4
1. +12V DC interlocked power jack
2. RS-232 control port (DB9)
3. HDMI Inputs 1 through 8
4. HDMI Outputs 1 through 8
5. External IR Receiver (3.5mm Stereo)
6. Ethernet Port
2
3
4
1
5
6
1
2
3
4
5
1. +5V DC interlocked power jack
2. RS-232 control port (DB9)
3. HDMI Inputs 1 through 4
4. HDMI Outputs 1 through 4
5. External IR Receiver (3.5mm Stereo)
