B-100 HDMATRIX Installation and Users Manual 4X4 & 8X8

pg.12

Sets EDID Based on All Connected Displays

Display Readout (Example)

1. Press DEFAULT

E-

2. Press Number Key 9

AA

4. Press ENTER

A0

Setting Auto EDID via IR Remote

4.2 Advanced EDID Configuration

4.2.1 Embedded EDIDs Defaults

The B-100-HDMATRIX switchers contain 8 representative ‘embedded’ EDIDs that may be

assigned to Inputs. These EDIDs define groups of video and audio capabilities that are

useful for configuring sources in most systems.

When to Use Embedded EDIDs

• When audio and video characteristics of displays are known and compatible with

the an Embedded EDID

Explanation of Embedded EDIDs

Video Resolution in the Embedded EDIDs is the highest resolution a connected source

will output; for example, if the source is capable of 1080P@60, it will be required by EDIDs

1-6 to provide that resolution. However, if the source is only capable of 1080i, it will output

1080i, etc. It is assumed that any display that can accept the specified Video Resolution can

also accept all standard video resolutions less than that specified.

Color Depth is the maximum number of bits used to encode color. 24bit color depth is

8bits per color (Red, Blue, Green) and 36bit color depth is 12 bits per color. When 36bit

color is used, the bandwidth increases substantially. This will dramatically reduce the

distance between the switch and the display when using an extender.

3D indicates that the source can output 3D if it is available in the content.

Audio Format indicates the maximum number of audio channels, as well as the audio

format that the source is allowed to output. For an Embedded EDID with 7.1ch Audio

Format, the source device will output the highest audio possible based on the content.

For example, if 7.1ch is not available and 5.1ch is, the output will be 5.1ch. The same holds

true if 2ch is the only audio available from the source.

Embedded EDIDs with 2Ch will limit output of the source to 2ch regardless of the formats

available in the content.

Embedded EDIDs 7 and 8 are provided for legacy displays that can only accept resolutions

up to a maximum of 1080i / 720p. The 1080i is listed first since almost all older HD displays

can accept 1080i, but not all can accept 720p. For these two Embedded EDIDs, (7&8) the

source will output 1080i. Should 1080i not be available, the source will output 720p. There

is a possibility that 720p may not work for a very small number of displays currently in use.

If you have such a display, you will need to use a Learned EDID (see below) from the display

to store in the Input EDID of any sources that will be routed to that display.
