B-100 HDMATRIX Installation and Users Manual 4X4 & 8X8

pg.18

5. SPECIFICATIONS

B-100-HDMATRIX-4x4

B-100-HDMATRIX-8x8

Technical

Product Type

True 4x4 HDMI matrix

True 8x8 HDMI matrix

HDMI compliance

Full HD 1080P60, Deep Color (36bit),

3D (1.4a 3D)

Full HD 1080P60, Deep Color

(36bit), 3D (1.4a 3D)

HDCP compliance

Version 2.0

Version 2.0

Video bandwidth

Single-link 225MHz [6.75Gbps total

bandwidth]

Single-link 225MHz [6.75Gbps total

bandwidth]

Video support

1080p / 1080i / 720p /480p / 480i

up to 36-bit color

1080p / 1080i / 720p /480p / 480i

up to 36-bit color

Audio support

Multi-Channel up to 7.1:

Dolby TrueHD

Dolby Digital Plus

DTS-HD Master

DTS-HD

LPCM

Dolby Digital EX

DTS-ES

Dolby Digital

DTS

2ch:

PCM

Multi-Channel up to 7.1:

Dolby TrueHD

Dolby Digital Plus

DTS-HD Master

DTS-HD

LPCM

Dolby Digital EX

DTS-ES

Dolby Digital

DTS

2ch:

PCM

ESD protection

ESD: IEC 61000-4-2 Level 4 (15KV)

Surge: IEC 61000-4-5

ESD: IEC 61000-4-2 Level 4 (15KV)

Surge: IEC 61000-4-5

Input

4x HDMI

1x RS-232

1x System IR (3.5mm jack)

8x HDMI

1x RS-232

1x System IR (3.5mm jack)

1x Ethernet Port

Output

4x HDMI

8x HDMI

HDMI Input selection

IR remote or RS-232

IR remote, RS-232 or Ethernet

IR remote control

21 button remote for Setup and

Operation

21 button remote for Setup and

Operation

HDMI connector

Type A [19-pin female]

Type A [19-pin female]

RS-232 connector

9-pin DB9 female

9-pin DB9 female

Ethernet Connector

N/A

RJ45

Mechanical

HousingV

Metal enclosure

Metal enclosure

Dimensions

(L x W x H)

Switcher

17” x 5.1” x 1.75”

17”x6.375”x1.75”

Package

21” x 10.4” x 3.1”

21”x10.4”x3.1”

Weight

4.4 lbs

5.4 lbs

Mounting

1RU rack-mount. Ears included

1RU rack-mount. Ears included

Power supply

5V 4A DC

12V 5A DC

Power consumption

20 Watts [max]

60 Watts [max]

Operation temperature

32~104°F]

32~104°F]

Storage temperature

-20~60°C -4~140°F

-20~60°C -4~140°F

Relative humidity

20~90% RH [no condensation]

20~90% RH [no condensation]
